test tube filling machine

test tube reagent/sampling tube with horizontal filling line
IA-Z CBD oil turnkey project whole filling line A-Z CBD oil turnkey project whole filling line

this whole line process：

1, tube vibrator
2，ball filling（option）
3，reagent filling
4，cap press
5，capping
6，labeling（option）
7，downflow（option）

reagent filling machine
Reagent filling machine feature:machine can according to client different liquid feature and different package demand, choose
different filling method, such as use peristaltic pump , piston pump,ceramic pump and so metering method. The main part of this
machine adopt 304 stainless steel, the part that touch the material adopt Medical grade material or 316L stainless steel, combine
with aluminum alloy material consist of whole machine, equipment comply to GMP demand. When the machine operate filling mouth can
up and down filling, prevent package material bubble and splash. Mould type design,change different specification product easy and
fast

Technical parameter:

filling volume
1-20ml(according to client)
capacity
30-40B/m 60-80B/M
compressed air
0.4-0.8Mpa
power supply
220V 50HZ or customize
capping rate
＞99%
dimension
2400*1100*1500mm
horizontal type labeing machine
Application and brief introduction
This machine mainly suit for various diameter small bottle but can't stand stable on the convey, labeling process stable and reliable, can make side self-adhesive label of the bottle very smooth, this machine structure simple and reasonable, have multi control system, no bottle no label paper out, prevent waste, no label or out of label automatic stop so on function. Comply to GMP requirement, widely use for pharmaceutical , foodstuff , chemical so on industrial.
Technical parameter

labeling machine
Application and brief introduction


Vertical type labeling machine belong to new generation series . it R&D special for automatic labeling process and technical requirement. Labeling process is stable and reliable, position of label fully meet the ideal requirement.

This vertical belong to electrical integration product, simple and reasonable structure , can automatic roll stick the self-adhesive label on the bottle body, no bottle no labeling, prevent waste of label paper, can according to bottle and self-adhesive label specification and feature make stepless speed adjust the production capacity

This labeling machine highly adaptable to round bottle for food industrial,pharmaceutical industrial and cosmetic etc， no matter use transparent or non transparent sticker, it can provide satisfactory labeling

Work principle
Transport the bottle that belong to previous process to convey belt, bottle through distance adjust device adjust the bottle distance and make bottle orderly into the photoelectric sensor area， the roller labeling machine drive by the step motor after get the signal then automatic supply label, correct no error automatic stick separate label to the bottle. Another photoelectric sensor make another label out in time. Under the continually bottle inlet label correct stick to the bottle, via roller press plat, automatic output, finished the whole labeling process.

Main technical parameter

1，label paper roller specification： adopt diameter ≤360mm self-adhesive label roller, roller max width 70mm, roller hole diameter76mm
2，Label paper specification： width 20mm-70mm
3，Bottle specification: diameter10mm-70mm
4，Labeling speed： 50-60 B/M (depend on bottle diameter and label length )
5，Power:2.9kw
6，Weight:200kg
7，Dimension：2000*700*1450mm（L*W*H）


output
200 bottle
bottle height
25-95mm
bottle diameter
12-30ml
label height
20-90 mm
label length
25-80mm
precision
¯0.5mm
power supply
220V/50Hz
machine weight( for your reference）
280Kg
machine dimension （for your reference）
2000*850*1700mm（L*W*H）
Main configuration
PLC
MITSUBISHI
servo motor
Mitsubishi
photoelectric sensor
F&C
convey motor
Aideli
EMS button
Schneider
