Zwy70 Track Belt Hydraulic Scraper Muck Loader
| Price: | US$ 28000 / Set |
|---|---|
| Minimum Order: | 1 set |
| Payment Terms: | L/C,T/T |
| Port of Export: | Guangzhou |
Product Details
| Model No.: | Zwy70 | Brand Name: | HUNAN YUTONG MINING EQUIPMENT |
|---|
| Certification: | CE, ISO9001:2008 |
|---|---|
| Specification: |
Model : ZWY70
Loading capacity m3/h : ≤70 Weight kg : 3100 Digging width mm : 3000 Digging height mm : 2150 Digging depth mm : ≤500 Digging distance mm : ≥1600 Gradeability ® : ≤5 Unloading height mm : 1500(Can be heightened) Unloading distance mm : 1600(Can be lengthened) Minimum turning radius ® : ≤5 Power kw : 15 Walking speed km/h : 1.45 Maximum passing size of material mm : 600×500 Wheelbase mm : 1550 Wheel distance mm : 1250 Adapation dimensions m : 2.2×2.2 Product dimensions mm : 5500×1600×1650 |
Packaging & Delivery
| Packaging: | 1 set per wooden box |
|---|---|
| Delivery/Lead Time: | In 15 days after payment |
| Production Capacity: | 1000 sets per year |
Product Description
Product Description
The multifunctional mine muck machine is a new type of loader developed to improve labor intensity and work efficiency. The machine can directly transport rocks to the conveyor belt. The machine adopts full hydraulic control mode, which is simple and convenient to operate. The gantry frame of the machine is detachable and non-cut, which is convenient for installation in the well. In addition, the height of the rear unloading can be adjusted according to the customer's own needs. The machine is equipped with an adventure device to solve the danger of manual exploration. This machine can be used in a cave below 2.2 meters, and the loading capacity per hour is between 40-60m±.
Application
Mine slag raking machine is mainly used for phosphate ore, aluminum ore, iron ore, copper ore, gold ore, silver ore, lead-zinc ore and other mines, hydropower, tunnel projects in narrow-space mining operations. And
transportation, construction and loading. The mining slag raking machine is a combination of a manipulator and a conveyor. The slagging and conveying and loading functions are combined into one. The production device adopts an electric full hydraulic control system. It has the characteristics of safety, environmental protection, low energy consumption, and high efficiency. It is an indispensable advanced mining equipment for mining enterprises and a substitute for labor and other machinery.
|
