ZRsuns 220/110V 40W CO2 laser power supply

ZR-40WD CO2 laser power supplies
Feature

1.Fast response speed and effect.
2.Dramatically lengthen the life time of sealed glass type CO2 laser.tube
3.Good compatibility:This 40W CO2 laser power supply is special designed for most brand 700mm,800mm or 850mm 30W /40watt CO2 laser tube. It mainly is used on mini laser carving stamp machine or laser engraver machine.
4.Easy Control: The start and stop of laser power can be easily controlled by TTL level. And it has protection switch to test the external water status, ventilation, etc.
5.The 40watt laser power supply has open circuit protection: Under the condition of good protective earth, this 40W CO2 power supply ’can work in open-circuit for a short time, which can protect power supply from damage. It can extend power supply’s service time.
6 Application: Acrylic sculpture, cut; Fabric sculpture, cut; Rubber sheet sculpture, cut, etc.
7.This CO2 laser power supply can take feedback interface which can be used in closed-loop control and testing the working current of laser power..
8.Easy control of laser power: Both 0-5V analog signal and PWM signal can be used to control laser power output.
9. This ZR-40WA CO2 power supply adopts ordinary H/L/P/G/IN/5V for control signal output and uses blue blue aluminum case.

Specification:
Item 40W laser power supply
Input Input voltage AC110/220V ®10%
AC frequency 47-440Hz
Max input power 350W
Max input current 3A
Output Max output voltage DC25KV
Max output current DC20mA(it depends on different brand 40watt CO2 laser tube)
Efficiency More than 90%(full load)
MTBF More than 10000 hours
Response speed 1ms(Time is from TTL.Signal is given to the output current up to 90% of pre-setting current)
Withstand voltage Input-output,input-enclosure, AC1500V,10mA 60S, Output cathode is connected with enclosure.
Environment Operation temperature(-10-40 degree celsius), related humidity s less than 90%
Cooling Force air cooling
Environment related Working temperature -20℃---50℃
Storage temperature -10℃---75℃
Related humidity Max 85^ RH(non-condensing)
Cooling method Force air cooling(FAC)
Altitude 100000feet of work,200000 feel of storage,no work.
Cooling method Air force cooling(Fan cooling)
Dimension LxWxH=165X144X80mm
Weight 1.15KG
