Wood grain tile cutting machine-multi blades cutting line

1. one 6mm smooth flat belt is used for conveying,
with a belt width of 1250mm; Variable frequency speed regulation, with an installed power of 2.2Kw.

2. Equipped with 3 groups of wheel cutters and one saw blade head cutting, the rear 2 sets are
independently adjustable for translation, with
an installed power of 0.37KW.

3. The sawing head adopts a 3KW long nozzle
motor directly connected to the saw blade, with
a diameter of Φ 250; Manual adjustment of
electric lifting of saw cutting head.

4. The wheel cutter is placed behind the sawing blade and pneumatically cut tiles, which can be manually adjusted left and right

5. Equipped with guiding device

6. Approximate overall dimensions (length x width
x height/mm): 3450x1600x1600

7. Total power (Kw): 11.94
