Tungsten Carbide Rotary Burr Die Grinder Bits for Metal

Tungsten Carbide Rotary Burr Die Grinder Bits for Metal

1. The Description of Tungsten Carbide Burr:

Carbide rotary burr is used with high-speed electric grinders orpneumatic tools,
which are widely used in industrial sectors such asmachinery,automobiles, ships,
chemicals, and crafts. Carbide rotary burr can be used to processmachine cast iron,
cast steel, carbon steel, alloy steel, stainless steel,hardened steel, copper and aluminum.

2. The Feature of tungsten rotary carbide burr:

Great efficiency, high degree of finish, long service life and high accuracy.
Easy to use, safe, reliable, economical and labor-saving.
Work with high-speed electric grinders or pneumatic tools..
Can process all kinds of metal(such as iron, steel,copper,aluminum) and non-metal (such as marble, jade, bone).
Widely used in machinery,automobile,ships,chemical,craft and more.
3.The recommended application of various types of tungsten carbide burr:

Arch ball/pointed nose – engraving, texturing, increasing hole size
Ball – concave cuts, hollowing, shaping, carving. Useful for wood, stone, metal engraving.
Ball nose cone – rounding edges, surface finishing, tight spaces, and angles.
carbide ball nose cylinder- contour finishing
Ball nose tree (also known as tapered) – concave cuts and rounding edges
Cone – rounding edges, surface finishing, tight spaces, hard to reach areas.
Cylindrical – contour finishing and right-angled corners
Cylindrical end cut – contour finishing
Carbide Cylindrical no end cut – contour finishing
Flame – channel work and shaping
Inverted cone – v-cuts and rear-side chamfering
Oval – die grinding and engraving
Pointed tree – concave cuts, rounding edges, access to hard-to-reach areas, and acute angles.
Rounded tree – concave cuts and rounding edges
4.Service supplied:

Full types for choice
OEM&ODM
Competitve price,stable quality,short lead time
Solid carbide burr,long shank carbide burr,carbide burr set supplied
Can engrave as requirement
Package:extension tube for one pieces(the color could be blue,yellow)
5.The details of three different types of cut shape of carbide burr:

Single cut burrs are primarily for general purpose fluting,milling,and cleaning,which produce long chips,and are ideal for heavy removal of material.

Double cut burrs creat small chips and a good finish,which are efficient at stock removal in harder materials.The additional flute reduce pull and increase operator control.Best for medium to light removal of material.It can be used at slower than normal speeds.

Coarse cut burrs(aluminum cut burr) remove stock quickly,and provide large flute area in softer ferrous and non-ferrous and non-ferrous materials.
