TEZ RAFTAR THREE WHEELER CARGO LOADER VEHICLE
| Price: | US$ 2300 |
|---|---|
| Minimum Order: | 3 UNITS |
| Payment Terms: | LC, T/T |
| Port of Export: | KARACHI |
Product Details
| Model No.: | Brand Name: | TEZ RAFTAR |
|---|
| Certification: | PSQCA |
|---|---|
| Specification: |
Engine Type & Capacity Single Cylinder, 4-Stroke, S.I., Water-cooled, Power Machine, 229cc
Starting / Ignition Electrical, Self-start Motor / Capacitor Discharge Ignition (CDI) Maximum Engine Output 11.5 kW / 7500 ¯500 rpm Maximum Engine Torque 18 N-m / 5000 ¯ 500 rpm Front - Telescopic Fork Suspension Two Shock Absorbers + Two Outer ‘Compression Coil Springs’ Rear – Double Leaf Spring Suspension 8 Laminated Leaf Springs + Two Coil Spring Assistors Shackles & Balancing Rods Four Shackles on Leaf Springs & Two Balancing Rods on each side Chassis Frame Type ‘Ladder Frame’ Chassis Design fabricated in ‘C’ Section Channels Transmission Clutch Method Manual Wet Multi-Plate Gear Shift Method Constant Mesh, Two-Stage Transmission, 5 Forward + 1 Reverse Front Brake Mechanical / Drum Brake Rear Brake Hydraulic / Drum Brake with Leading and Trailing Shoes Gross Vehicle Weight (GVW) 1070 kg Kerb Weight 470 kg Tyre Size and Type 5.00 – 12”, 8 Ply Rating Dimensions of Vehicle Overall Length 3530 mm Overall Height 1850 mm Carry Box Dimensions (L x W x H1/H2) 2030 mm x 1330 mm x 890 mm / 565 mm Wheel Base 2340 mm Wheel Track 1150 mm Turning Circle Radius 4050 mm System Voltage 12 V Battery 12 V, 36 Ah |
Packaging & Delivery
| Packaging: | EXPORT STANDARD |
|---|---|
| Delivery/Lead Time: | 30 DAYS |
| Production Capacity: | 1000 UNITS PER MONTH |
Product Description
Dimensions of Vehicle
Overall Length 3530 mm
Overall Height 1850 mm
Carry Box Dimensions (L x W x H1/H2) 2030 mm x 1330 mm x 890 mm / 565 mm
Wheel Base 2340 mm
Wheel Track 1150 mm
Turning Circle Radius 4050 mm
System Voltage 12 V
Battery 12 V, 36 Ah
For other detailed features, please contact Mr. Gulzar A. Butt, Director via email at Email: * and/or Whats-app: +92 300 848 2202
|
