Security gate door frame walk through security gates metal detector

Security gate door frame walk through security gates metal detector





Model HPC-E33
Name walk through metla detector
Function entrance security checking
Brand PEACENTURY
Certificate Ce, Iso, Rohs, Fcc
Warranty 2 years


Technical parameter

Electric current: AC85v-264v, 50/60HZ

Power:<20W

Net weight:75KG

Workplace environment: -20℃+55℃

Alarm: Sound Alarm&LED light alarm

Inner size: 2000mm*700mm*500mm

Outer size: 2200mm*800mm*580mm

Door panel Material: fibreboard+ABS plastics

Standard: ISO, FCC, ROHS, CE



Characters& Function

1. 7 inch color LCD screen with infrared remote control.

2. Sensitivity adjustable: Each zone has sensitivity level from 0-255,

whole sensitive level adjustment: 0-4095

3. 6 detecting zones as standard could extend to be 12, 18 zones;

4. metal density indicator on the panel, low power indicator

5. Automatically 6 digital numbers count passengers in and out both sides and alarm times

6. 2 columns LED bar graph on both door panels to show alarm location, could be customized 4 led bar graph as per requests.

7. backup batteryas standard, could be working 4-6 hours; waterproof level IP54.

8. Network supportas standard, one PC could control about 15-20pcswalk through metal detector.

9. Output Signal to connect turnstile(for option)

10. Camera Function: capture or take video(for option)

11. Adjustable passing speed: up to 100 persons/min



Harmless to human body, such as heart pacemaker, pregnant women, magnetic floppy, recording tapes, etc.

Easily detect weapons, such as knife and gun, and any metal articles which are hidden in human body.



Application:

Government, court, airport, prison, customs, Entertainment environments, Gymnasiums, Exhibition Centers, factory and so on.
