ST907V3.0 Android Tablet PC with 1D/2D

Price:	US$ 400 / Unit
Minimum Order:	1 unit
Payment Terms:	T/T, Paypal, Western Union and Moneygram
Port of Export:	Qingdao

Product Details

Model No.:	ST9073.0	Brand Name:	SENTER

Certification:	CE/ROHS/3C/FCC/IP67
Specification:	Standard function Operating System Android 7.1 CPU MSM8953, 8 core CPU, 2 GHz RAM RAM: 4GB FLASH: 64GB Extended Storage Micro SD, Maximum 128G USB port 5 pin MicroUSB; Support to connect U-disk/Mouse/Keyboard/OTG line OTG Through OTG can meet 100M network port, network card setup, PPPoE dial-up, web browsing. Support OTG extend RS232 serial port/485 serial port/RJ45 Serial port External port Charge port, headphone port Protection Grade Industrial Protection Grade IP67 Drop Grade Drop resistance from 1.2m Wireless Communication Bluetooth Support 4.0 GPS GPS+BDS+A-GPS+GLONASS: accuracy 10m Accuracy 3m Module: Hisense H1 Accuracy: Autonomous 2.5m SABS 2m Module: Ublox M8N WIFI Support IEEE 802.11a/b/g/n/ac, 2.4G and 5G 2G/3G/4G CDMA 1X/EV BC0 GSM 850/900/1800 WCDMA B1/B5/B8 TD-SCDMA B34/B39 LTE B1/B3/B5/B7 B38/B39/B40/B41N Physical Parameters Display Screen 8 inch LCD screen, 8001200 IPS screen, capacitive touch screen Optional: 19201200 IPS screen Keyboard Android menu, Homepage, Return, Volume, Barcode, ON/OFF, Reset Camera 5 million pixels front camera, 13 million pixels rear camera with automatic focus and lighting function Headset 3.5mm audio Interface, has MIC and Single loudspeaker LED indicator light Support (ordinary flicker, Call fast flicker, missed calls, charge indicator) Flashlight Function S Support, can be used for emergency lighting Googleplay store S Support  Gravity sensor Support  Compass Support Acceleration sensors Support Light and distance sensor Support Vibrating motor Support FM Support Rechargeable Lithium Battery 3.8V, 10 000mAh Standby Standby current less than 10mA Dimension 23215822 Weight 810g Environmental Characteristics Working Temperature -10℃ ~ +50℃ Storage Temperature -40℃ ~ +60℃ Humidity 5%-95% relative humidity; no condensation Optional function Far infrared meter reading Working frequency 37.9K Barcode Scanning 1D Laser Scanner Index(Internal): Honeywell N4313 or Zebra EM1350 Scanning speed: 104 times/second+12 times/second (two way scanning) Scanning distance: 2.5cm-114.3cm Scanning angle: 47¯3®(default) /35¯3®(reduced code) 2D Barcode Scanner Index(Internal): Newlands EM3096 Honeywell N3680 Motorola SE4710 Motorola SE4750 Honeywell N6603 Identification ability: 1D, 2D, OCR Scanning angle: rotate 360®, incline¯50®, deflection ¯50® Field of View: Horizontal 36®, vertical 23® Depth of field: 4cm-23.5cm Environmental luminance: 0~100,000 LUX RFID HF RFID(Internal): Support NFC/NXP, 13.56MHZ ISO14443A,B and ISO15693 protocol, reading distance 0-3cm LF RFID: 134.2KHZ LF RFID, support ISO11784/5 protocol, support to read IC card(FDX/HDX) 125KHZ LF RFID, support to read ID card UHF RFID Internal ThingMagic NANO Working frequency: 865 to 868 MHz Supported agreement: EPC C1 GEN2/ISO 18000-6C Output power:10dBm-30dBm Ceramic antenna: 0.3db(25254mm)

Certification:

CE/ROHS/3C/FCC/IP67

Specification:

Standard function
Operating System Android 7.1
CPU MSM8953, 8 core CPU, 2 GHz
RAM RAM: 4GB
FLASH: 64GB
Extended Storage Micro SD, Maximum 128G
USB port 5 pin MicroUSB; Support to connect U-disk/Mouse/Keyboard/OTG line
OTG Through OTG can meet 100M network port, network card setup, PPPoE dial-up, web browsing. Support OTG extend RS232 serial port/485 serial port/RJ45 Serial port
External port Charge port, headphone port
Protection Grade
Industrial Protection Grade IP67
Drop Grade Drop resistance from 1.2m
Wireless Communication
Bluetooth Support 4.0
GPS GPS+BDS+A-GPS+GLONASS: accuracy 10m
Accuracy 3m
Module: Hisense H1
Accuracy: Autonomous 2.5m SABS 2m
Module: Ublox M8N
WIFI Support IEEE 802.11a/b/g/n/ac, 2.4G and 5G
2G/3G/4G CDMA 1X/EV BC0
GSM 850/900/1800
WCDMA B1/B5/B8
TD-SCDMA B34/B39
LTE B1/B3/B5/B7 B38/B39/B40/B41N
Physical Parameters
Display Screen 8 inch LCD screen, 800*1200 IPS screen, capacitive touch screen
Optional: 1920*1200 IPS screen
Keyboard Android menu, Homepage, Return, Volume, Barcode, ON/OFF, Reset
Camera 5 million pixels front camera, 13 million pixels rear camera with automatic focus and lighting function
Headset 3.5mm audio Interface, has MIC and Single loudspeaker
LED indicator light Support (ordinary flicker, Call fast flicker, missed calls, charge indicator)
Flashlight Function S Support, can be used for emergency lighting
Googleplay store S Support
 Gravity sensor Support
 Compass Support
Acceleration sensors Support
Light and distance sensor Support
Vibrating motor Support
FM Support
Rechargeable Lithium Battery 3.8V, 10 000mAh
Standby Standby current less than 10mA
Dimension 232*158*22
Weight 810g
Environmental Characteristics
Working Temperature -10℃ ~ +50℃
Storage Temperature -40℃ ~ +60℃
Humidity 5%-95% relative humidity; no condensation
Optional function
Far infrared meter reading Working frequency 37.9K
Barcode Scanning 1D Laser Scanner Index(Internal):
Honeywell N4313 or Zebra EM1350
Scanning speed: 104 times/second+12 times/second (two way scanning)
Scanning distance: 2.5cm-114.3cm
Scanning angle: 47¯3®(default) /35¯3®(reduced code)
2D Barcode Scanner Index(Internal):
Newlands EM3096
Honeywell N3680
Motorola SE4710
Motorola SE4750
Honeywell N6603
Identification ability: 1D, 2D, OCR
Scanning angle: rotate 360®, incline¯50®, deflection ¯50®
Field of View: Horizontal 36®, vertical 23®
Depth of field: 4cm-23.5cm
Environmental luminance: 0~100,000 LUX
RFID HF RFID(Internal):
Support NFC/NXP, 13.56MHZ ISO14443A,B and ISO15693 protocol, reading distance 0-3cm
LF RFID: 134.2KHZ LF RFID, support ISO11784/5 protocol, support to read IC card(FDX/HDX)
125KHZ LF RFID, support to read ID card
UHF RFID
Internal
ThingMagic NANO
Working frequency: 865 to 868 MHz
Supported agreement: EPC C1 GEN2/ISO 18000-6C
Output power:10dBm-30dBm
Ceramic antenna: 0.3db(25*25*4mm)

Packaging & Delivery

Packaging:	Box
Delivery/Lead Time:	After paymetn 3 work days
Production Capacity:	3000 units in one month

Product Description

Advanced system
Android 7.1 operating system; CPU MSM8953, 8 core, 2 GHz CPU; RAM 4GB ROM 64GB, Micro SD 128G
Visible under strong light
8 inch LCD screen, 800*1280 IPS capacitive touch screen
Optional: 1920*1200 IPS capacitive touch screen
Powerful function
Multi function information acquisition configuration (1D/2D bar code scanning, LF/HF/UHF RFID reader, fingerprint identification)
Multi communication modes
3G/4G, WIFI, Bluetooth and many wireless communication modes
Support jacket extension
Satisfy custom applications from customers
Certification
CCC/CE/ROSH/FCC/IP67/MIL-STD-810
Docking Station
Make the tablet charging easier
