SO 2531 EN 545 EN598 Ductile Iron COMPACT Loosing Flanged Pipe Fittings
| Price: | US$ 1.8 / Kilogram |
|---|---|
| Minimum Order: | 10 |
| Payment Terms: | L/C,T/T |
| Port of Export: |
Product Details
| Model No.: | Loosing Flanged Pipe | Brand Name: | SYI |
|---|
| Certification: | |
|---|---|
| Specification: | SYI COMPACT Loosing Flanged Pipe Fittings is the newest design, most light and most competitive ductile iron loosing flanged fittings in the market. SYI can supply the loosing flanged fittings with PN10, PN16, PN25 drilling in accordance with ISO 7005-2/EN1092-2, from DN80 to DN600, with the coating of Zinc and Black Bitumen coating, Red/Blue Epoxy coating, or PU (polyurethane) coating. |
Packaging & Delivery
| Packaging: | Standard export package or as per your requirements |
|---|---|
| Delivery/Lead Time: | |
| Production Capacity: |
Product Description
SYI COMPACT Loosing Flanged Pipe Fittings FEATURE
1. After two years of new design and mold development, SYI COMPACT Loosing Flanged Pipe Fittings have formed a production scale.
2. Compared with the traditional loosing flanged pipe fittings, its structure size is more reasonable, operation and installation are easier, weight is lighter. The unit price is more attractive and competitive
SYI COMPACT Loosing Flanged Pipe Fittings---The Newest Design!
Most reasonable
Most light
Most competitive
Quality & Efficiency improved
Material:
Body：
Ductile iron grade 500-7/ 450-12 in accordance with ISO 1083.
LOOSING FLANGE：
Ductile iron grade 500-7/ 450-12 in accordance with ISO 1083.
Loosing Flange：
PN10, PN16 or PN25 drilling in accordance with ISO 7005-2/EN 1092-2.
Fluid Temperature:
0®C-50®C, excluding frost.
Coating：
External coatings:
zinc coating +bitumen painting;
liquid epoxy resin painting;
epoxy applied by FBE；
according to customers' requirements.
Internal coatings：
cement mortar lining;
liquid epoxy resin painting;
epoxy applied by FBE；
according to customers' requirements.
|
