Reduced Bore Ball Valve,150LB.WCB,DN80XDN65
| Price: | US$ 100 |
|---|---|
| Minimum Order: | 1PC |
| Payment Terms: | T/T |
| Port of Export: | shanghai |
Product Details
| Model No.: | Q41 | Brand Name: | STV |
|---|
| Certification: | ISO9001 |
|---|---|
| Specification: | China Reduced Bore Ball Valve Manufacturers And Suppliers,Stv Provides Reduced Bore Ball Valve,150LB.WCB,DN80XDN65 |
Packaging & Delivery
| Packaging: | WOODCASE |
|---|---|
| Delivery/Lead Time: | 30DAYS |
| Production Capacity: | 1000PCS |
Product Description
Valve Details:
Design standard: API 6D.
Body material: WCB
Nominal diameter: 3x21/2 Inch.
Pressure: 150lb.
End connection；RF.
Face to face: ASME B16.10.
Working temperature: -29℃~+200℃.
Test and inspection: API 598.
Product Range
Body material: Carbon Steel, Stainless Steel, Alloy Steel.
Normal diameter: 1/2"~8" (DN15~DN200).
End connection: ASME B16.5,EN 1092,JIS B2220
Pressure range: 150 lbs (PN16~JIS10K).
Operation: Lever, Gearbox, Electric, Pneumatic, Electro Hydraulic Actutor, Gas Over Oil Actuator.
Working temperature: -46℃~+200℃.
