Printed Circuit Board PCB Assembly OEM Service from Makerfabs
| Price: | US$ 0.08 / Piece |
|---|---|
| Minimum Order: | 1 pcs |
| Payment Terms: | T/T, Paypal, Credit Card, Western Union |
| Port of Export: | Shenzhen |
Product Details
| Model No.: | PCBA | Brand Name: | Makerfabs |
|---|
| Certification: | |
|---|---|
| Specification: |
Layers 1/2/4
PCB Material FR-4 Thickness Tolerance (t≥1.0mm) 10% Thickness Tolerance (t<1.0mm) 0.1mm Insulation Layer Thickness 0.075mm--5.00mm Minimum PCB track 6mil Minimum Track/Vias Space 6mil Minimum pads Space 8mil Minimum silkscreen text size 32mil Inner Layer Copper for 4-layer PCB 17um Drilling Hole (Mechanical) 0.3mm—6.35mm Finish Hole (Mechanical) 0.8mm—6.35mm Drill Diameter Tolerance (unplated) 0.05mm Drill Diameter Tolerance (plated) 0.1mm Outline Tolerance (Mechanical) 0.20mm Aspect Ratio 8:1 Solder Mask Type Photosensitive ink SMT min Solder Mask Width 0.2mm Min Solder Mask Clearance 0.2mm Solder Mask Thickness 15um |
Packaging & Delivery
| Packaging: | Inner ESD vacuum packing,outer standard carton box; |
|---|---|
| Delivery/Lead Time: | 12-14 business days |
| Production Capacity: | 100000pcs/ Month |
Product Description
Makerfabs provides the turnkey service for makers& startups to create the first prototyping board to the mass production, includes the PCB/ Components Sourcing/ Soldering/ Programming/ Testing and end shipping. Our responsive team will offer you PCB assembly services with a range of process control, refined and strict PCB assembly workflow and quality commitment. With this service, you do not need to suffer from these very detailed work such as soldering the prototype board, and thus can concentrate on the creating and designing.
|
SUPPLIER PROFILE
|
|||
|---|---|---|---|
| Company: | Makerfabs | ||
| City/State | Shenzhen, Guangdong | Country: |
China
|
| Business Type: | Export - Manufacturer / Trading Company | Established: | 15 |
| Member Since: | 2017 | Contact Person | Helen He |
