Plasma cutting machines for iron/steel plate cutting with good price

Plasma cutting machines are used for iron/steel plate cutting, if you have big size metal to cut, the portable and table type are all not suitable. You need choose gantry type plasma cutting machines, but it price is very high. So we design this kind plasma cutting machines that can cut big size iron/steel plate with good price.
Features of plasma cutting machines:
1 .The machine is all welded as seamless steel structure. Steady structure and long life time
2. High configuration, high cutting speed and precision.
3., Auto ARC starting. Steady performance.
4, Control system: STARFIRE control, with USB interface
5. Cutting material: steel, copper, iron, aluminum, galvanized sheet, titanium plates, and so on.
6. File format: G-code
7, Suitable Software: CAD, ART CUT, Type, Art CAM etc

Parameters of plasma cutting machines
Working Voltage 3-Phase 380V/2-phrase 220V
Working Area(X*Y)
2000*3000mm, 2000*4000mm, 2000*5000mm, 2000*6000mm
Machine Structure Welded
X Y Guide Rail Taiwan HIWIN Square Rail
X Y Transmission Imported Rack gears
Drive Mode Stepper Motor (Optional Servo )
Control System STARFIRE
Max thickness 30mm
Plasma Generator 63A/100A /120A/160A/200A
Cutting Speed 0-10000mm/min
G.W. 1500KGS

After-sale service of plasma cutting machines:
→2 years quality guaranty.
→Lifetime maintenance free of charge.
→Free training course at our plant.
→Machine has been adjusted before delivery. You can operate it normally when you received.
→Providing distance teaching.
→24 hours on line service and email each day, free technical support.
