PEACENTURY 6550 58db lower noise airport baggage security equipment X-Ray Baggage Scanner

PEACENTURY 6550 58db lower noise airport baggage security equipment X-Ray Baggage Scanner



Technical Specifications

Tunnel Size:650(W)*500(H)mm

Power Requirement::220VAC(¯10%)50¯3Hz

Power Consumption:1.0 KW (max)

Noise: <58db

Conveyor Speed:0.22m/s

Conveyor Max Load:100kg

Sensitivity: 42WG Typical, 40WG Guaranteed

Spatial Resolution: 1.0mm Horizontal and Vertical

Penetration resolution: dia 0.254mm

Penetration: 28-38mm steel

Dose per Inspection: < 1.2μGy/h

X-ray Leakage:0.0μGy/h (at a distance of 5cm From external housing)

Film Safety: Guarantee ISO1600 Film



X-ray Generator Specifications

Voltage: 100KV to 160kv

Tube Current: 0.4mA to 1.2mA

Cooling: Sealed Di-Electric Oil Bath with Forced Air.

Duty Cycle: Rated for 100% Duty Cycle

Beam Direction: Upward

Beam anger:80 degree

Detector: 1024 Channels in an L-Shaped Array



Image Display

Single 17’’ High Resolution, low Radiation, Ergonomic LCD Color Monitor

Display Resolution: 1280*1024; 24 bit/pixel Color

Contrast Sensitivity: 24 Visible Levels, 4096 Gray Level

Image storage: 100000 pictures in real time

Zones & Zoom:1-9 Image regions, 64 Times Enlarge, Whole screen continuous observation

Processing: Edge enhancement, image strengthening, image lightening, reducing darkening,image returning, image retrieval.

Multi-Energy (M) color material identification: Organic objects in orange, inorganic objects in blue, mixture in green



Environmental Specifications

Operating Temperature: 0®C-45®C

Storage Temperature:-20®C-60®C

Humidity: Up to 95% Non-Condensing



Computer Specifications

Processor: Intel(R)Dual CPU 2.0

Memory: 1GB RAM

Storage: 160GB HDD

Video Card: 256 Video Card (digital Display)

Platform: Windows XP Pro



Standard Features

Auto Image Archiving

Baggage Counter

Color and Black/ White Imaging

Density Alert

Edge-Enhancement Imaging

High Penetration

Image Annotation

Image review

Manual Archive (bitmap)

Suspect Image Archive

Operation Training Program

Picture Perfect

Print Image

Programmable Penetration

Programmable Contrast

Pseudo Color

Reverse Monochrome

Real-Time Image Manipulation

User Defined Access

Zoom 2X to 64X

High-energy/low energy: Switch from high energy to low energy

Assist to detect drug and explosive powder


SHENZHEN HEPING CENTURY TECHNOLOGY CO., LTD （PEACENTURY）is a professional security scanner equipment manufacturer, specialized the development and research in the x-ray imagine technology, metal detection technology, explosive detection, liquid detection and relative security services.

We owns all of the intellectual property rights (IPR) to its core technologies ,and have a experience engineer team with senior x-ray detection exports, signal and imagine processing specialist , excellent technical support and maintance engineers.

We always adhere to customer-centric, the principles of honesty and trustworthiness, is committed to efforts to improve and continuous innovate its own responsibility .
