Original Printhead Ricoh GEN3-E3 (MH1603/1803/1903)
| Price: | US$ 860 / Unit |
|---|---|
| Minimum Order: | 1 |
| Payment Terms: | T/T / Bank Wire / Paypal |
| Port of Export: |
Product Details
| Model No.: | GEN3-E3 | Brand Name: | Ricoh |
|---|
| Certification: | |
|---|---|
| Specification: |
Size: 7.8 x 120 x 35 mm (excluding cables)
Head materials: SST, Pd and Epoxy Adhesive Nozzle plate surface: Non-coated SST Number of nozzles: 192 nozzles Nozzle spacing: 0.3387 mm Piezo type: D33 Stacked PZT Temperature control: Integrated Heater and Thermistor Operator temperature range: Up to 80® C Native drop volume: 30 pl - 45 pl Drop volume range: 12-50 pl Jetting frequency: Up to 30 kHZ Life: 100 billion actuations per nozzle Printer compatibility: DYSS Apollo UV R220 |
Packaging & Delivery
| Packaging: | Original In Box |
|---|---|
| Delivery/Lead Time: | 6-7 days |
| Production Capacity: |
Product Description
This Ricoh GEN3-E3 (MH1603/1803/1903) printhead is suitable for DYSS Apollo UV R220 printers. This is the original Ricoh part.
Product Specifications
Size: 7.8 x 120 x 35 mm (excluding cables)
Head materials: SST, Pd and Epoxy Adhesive
Nozzle plate surface: Non-coated SST
Number of nozzles: 192 nozzles
Nozzle spacing: 0.3387 mm
Piezo type: D33 Stacked PZT
Temperature control: Integrated Heater and Thermistor
Operator temperature range: Up to 80® C
Native drop volume: 30 pl - 45 pl
Drop volume range: 12-50 pl
Jetting frequency: Up to 30 kHZ
Life: 100 billion actuations per nozzle
Printer compatibility: DYSS Apollo UV R220
This Ricoh GEN3-E3 (MH1603/1803/1903) printhead is suitable for DYSS Apollo UV R220 printers. This is the original Ricoh part.
Product Specifications
Size: 7.8 x 120 x 35 mm (excluding cables)
Head materials: SST, Pd and Epoxy Adhesive
Nozzle plate surface: Non-coated SST
Number of nozzles: 192 nozzles
Nozzle spacing: 0.3387 mm
Piezo type: D33 Stacked PZT
Temperature control: Integrated Heater and Thermistor
Operator temperature range: Up to 80® C
Native drop volume: 30 pl - 45 pl
Drop volume range: 12-50 pl
Jetting frequency: Up to 30 kHZ
Life: 100 billion actuations per nozzle
Printer compatibility: DYSS Apollo UV R220
|
