Large slab online cutting machine for Ceramic&porcelain tile and sintered stone
| Price: | US$ contact |
|---|---|
| Minimum Order: | 1 line |
| Payment Terms: | 30% down payment,70% before delivery |
| Port of Export: | Shekou,Yantian Or Nansha |
Product Details
| Model No.: | LSC-1632 | Brand Name: | Aitao |
|---|
| Certification: | |
|---|---|
| Specification: |
Maximum cutting size : 1600x3200mm
Maximum cutting thickness:12mm. Cutting speed:2~4pcs/min |
Packaging & Delivery
| Packaging: | |
|---|---|
| Delivery/Lead Time: | 30-60 days |
| Production Capacity: | 100 lines |
Product Description
Large slab online cutting machine for Ceramic&porcelain tile and sintered stone
1.This line ordinary is composed of loading machine or robot hand+ main cutting machine+suction cup machine,and then connected to big grinding machine.
2.. Using four 7x90 (mm) flat belts for conveying; Variable frequency speed regulation, with an installed power of 1.5Kw.
3. Wheel cutter frequency conversion speed regulation, with an installed power of 1.1Kw.
4. Use pneumatic jacking to separate the tiles into 2 pieces.
5. Machinable tile specification (mm) 1600x3200
6. Cutting speed: 2-4pcs/min
7. Approximate overall dimensions (length x width x height/mm): 4240x2600x1155
8.Order to be subject to the final approval drawings and technical document.
9.Extra cost will be beared by customer if change happens when order is confirmed and material is ready to be produced.
|
