LOWBED TRAILER PRICE TRAILER MANUFACTURER

Main Features

1. Torsion - resistance of side beam and Main Beam are with "I" high strengh steel. more durable than normal trailer steel to ensure low bed trailer driving stability and handle bed roads.

2. Heavy duty type ramp: manganese plate butt welding, This design that ensure the ramp support the heavy duty marchine safely.

3. Stability when loading heavy duty marchine. Our low bed trailer can equipped with extra legs on the rear of trailer. This will enable you to  load machines safely

According to clients' requirements, we can customize different axles and loading weight.

The popular lowboy trailer models as follows:

2 axles 40 ton lowbed semi trailer

3 axles 60 ton low bed truck trailer,

3 axles 80 ton low loader trailer

3 axles 100 ton lowbed truck trailer

2 line 4 axles 60 ton lowbed trailer

3 line 6 axles 120 ton low bed trailer







Specification:

Type Low Bed Semi Trailer
Loading Capacity 40-60T
Axle 3 Pieces, 13T FUWA/BPW axle
Tyre 12 Pieces, 10.00R20
Dimensions(L*W*H) 13000-18000*3000-3200*1750mm
Weight 10 tons to 14 tons
Rims 5.5-20, 9.0-20
Suspension System Leaf Spring Suspension/ Air Suspension
Brake System Dual line pneumatic brake system with WABCO valve
Main Beam Height 500mm HG60 steel
Chassis upper 20mm, bottom 20mm. Mid web 12mm
Ramps Safety chain
Kingpin 2' or 3.5' interchangeable, JOST brand
Landing Gear 28 tons, Two speed manual operation
Electrical System Voltage: 24V   Receptacle: 7 ways Germany standard
Painting Antirust painting two layers
Tool Box One tool box with a set of standard trailer tools
Spare Tyre Rack One piece or Two pieces
Warranty  10 years
Export Port Tianjin Port
