Gate Valve Pressure Seal Class 1500LB , Wcb Body , 5 Trim , Psb , OS&Y , Bw Sch.80
| Price: | US$ 100 |
|---|---|
| Minimum Order: | 1PC |
| Payment Terms: | T/T |
| Port of Export: | shanghai |
Product Details
| Model No.: | Z41 | Brand Name: | STV |
|---|
| Certification: | ISO9001 |
|---|---|
| Specification: | Gate Valve Pressure Seal Valve Class 1500LB Manufacturer Stv Provides Gate Valve Pressure Seal Class 1500LB , Wcb Body , 5 Trim , Psb , Os&y , Bw Sch80 |
Packaging & Delivery
| Packaging: | WOODCASE |
|---|---|
| Delivery/Lead Time: | 30DAYS |
| Production Capacity: | 1000PCS |
Product Description
Product Detail
Design standard: BS 1873.
Body material: WCB.
Nominal diameter: 6" (DN150).
Pressure: 1500 LB (PN250).
End connection: BW.
Face to face: ANSI B16.10.
Working temperature: -29℃~+425℃.
Test and inspection: API 598.
Product Range
Body Material: Carbon Steel, Stainless Steel, Alloy Steel.
Normal diameter: 1/2"~24" (DN15~DN600).
End connection: BW, Flanged.
Pressure range: 150 LBs~2500 LBs (PN16~PN420).
Operation: Handwheel, Gearbox, Electric, Pneumatic.
Working temperature: -29℃~+560℃.
Product Keywords of Gate Valve Pressure Seal Class 1500LB , Wcb Body , 5 Trim , Psb , OS&Y , Bw Sch.80
|
SUPPLIER PROFILE
|
|||
|---|---|---|---|
| Company: | STV Valve Technology Group Co.,Ltd | ||
| City/State | wenzhou, Zhejiang | Country: |
China
|
| Business Type: | Export - Manufacturer / Trading Company | Established: | 2003 |
| Member Since: | 2018 | Contact Person | boobo gao |
