Forged Gate Valve,A105 Body, DN20,600LB,RF End
| Price: | US$ 100 / Piece |
|---|---|
| Minimum Order: | 1PC |
| Payment Terms: | T/T |
| Port of Export: | shanghai |
Product Details
| Model No.: | Z41 | Brand Name: | STV |
|---|
| Certification: | ISO9001 |
|---|---|
| Specification: | Stv is one of the leading Manufacturers, Supplier and Exporters of Gate Valve in Stainless Steel Carbon Steel Forged Steel nickel Alloy Steel Inconel Monel Hastelloy Titanium Alloy and Special Steel. |
Packaging & Delivery
| Packaging: | WOODCASE |
|---|---|
| Delivery/Lead Time: | 30DAYS |
| Production Capacity: | 1000PCS |
Product Description
Product Detail
Design Standard: API602.
Body Material: A105
Nominal Diameter: 3/4 Inch (DN20).
Pressure: Class 600 .
End Connection: RF.
Face to Face: ASME B16.10.
Working Temperature: -29℃~+425℃.
Mode of Operation: Handwheel.
Test and Inspection: API 598.
Product Range
Body Material: A105、LF2、F5、F11、F22、304、304L、316、316L、F51、F91、20#、Inconel .Ect
Normal diameter: 1/2"~2" (DN15~DN50).
End connection: NPT, SW, Butt-Weld, Flanged.
Pressure range: 150lbs~2500lbs(PN10~PN420).
Operation: Hand wheel, Electric,Pneumatic Actuator
Working temperature: -196℃~ +560℃.
Product Keywords of Forged Gate Valve,A105 Body, DN20,600LB,RF End
|
