Flange Trunnion Mounted Ball Valve, ASTM A105, 2 Inch, 600 LB
| Price: | US$ 100 |
|---|---|
| Minimum Order: | 1PC |
| Payment Terms: | T/T |
| Port of Export: | shanghai |
Product Details
| Model No.: | Q41 | Brand Name: | STV |
|---|
| Certification: | ISO9001 |
|---|---|
| Specification: | China Flange Trunnion Mounted Ball Valve manufacturer Stv provides Flange Trunnion Mounted Ball Valve, ASTM A105, 2 Inch, 600 LB,PEEK Seat,API 6D, API 598, ASME B16.10 |
Packaging & Delivery
| Packaging: | WOODCASE |
|---|---|
| Delivery/Lead Time: | 30DAYS |
| Production Capacity: | 1000PCS |
Product Description
Product Detail
Valve Description:
Design standard: API 6D.
Body material: ASTM A105.
Nominal diameter: 2 Inch.
Pressure: 600 LB.
End connection: RTJ.
Face to face: ASME B16.10.
Working temperature: -29℃~+200℃.
Test and inspection: API 598.
Product Range
Body material: Carbon Steel, Stainless Steel, Alloy Steel.
Normal diameter: 2"~60" (DN50~DN1500).
End connection: BW, Flanged.
Pressure range: 150 lbs~2500 lbs (PN16~PN420).
Operation: Lever, Gearbox, Electric, Pneumatic, Electro Hydraulic Actutor, Gas Over Oil Actuator.
Working temperature: -46℃~+200℃.
Product keywords of Flange Trunnion Mounted Ball Valve, ASTM A105, 2 Inch, 600 LB
|
