DGFQ JUMBO PAPER ROLL SLITTING MACHINE HIGH SPEED PAPER ROLL SLITTER REWINDER MACHINE

DGFQ JUMBO PAPER ROLL SLITTING MACHINE HIGH SPEED PAPER ROLL SLITTER REWINDER MACHINE
Gaobao thermal paper roll cutting machine is suitable for slitting and rewinding various jumbo roll materials, such as 40g/㎡-260g/㎡ roll paper, coated paper, special paper, white cardboard, kraft paper, coated paper, coated paper, plastic composite materials and so on. If you want more information about the jumbo paper roll slitting and rewinding machine, paper roll slitter and thermal paper roll cutting machine price, Please do not hesitate to contact the Gaobao paper slitting machine supplier.

CHARACTERISTICS OF GAOBAO DGFQ JUMBO PAPER ROLL SLITTING MACHINE HIGH SPEED PAPER ROLL SLITTER REWINDER MACHINE
The jumbo paper roll slitting and rewinding machine adopts five servo motor synchronous control, Automatic taper tension structure, Surface coiling mode;

Paper roll slitting machine use frequency converter adjust speed, keep stable running when speed go up;

Automatic loading, automatic edge position correct, automatic count meter, automatic constant tension control, alarm and other functions;

Winding adopts shaftless clamping and rewinding structure, the press roll is controlled by hydraulic system, push arm automatically push material, automatic tipper hydraulic discharge is easy to operate;

A. Unwinding adopts static analogue ultrasonic wave (Taiwan Puliyuan);

B. Automatic discharge device for waste edge cutting with round knife;

C. Hydraulic automatic shaftless feeding frame structure.

SPECIFICATION OF GAOBAO DGFQ JUMBO PAPER ROLL SLITTING MACHINE HIGH SPEED PAPER ROLL SLITTER REWINDER MACHINE
Model DGFQ-2000
Max. Width of unwinding 2000mm
Max. diameter of unwinding 1500mm
Max. diameter of rewinding 1500mm
Precision ¯0.2mm
Speed 0-800 m/min
Total Power 130kw
Power supply 380V/50hz
Overall dimension 6250×5300×2600 mm
Weight About 22 T

APPLICATIONS OF GAOBAO DGFQ JUMBO PAPER ROLL SLITTING MACHINE HIGH SPEED PAPER ROLL SLITTER REWINDER MACHINE
The Gaobao DGFQ Jumbo Paper Roll Slitting and Rewinding Machine is a high-speed paper roll slitter rewinder machine that is designed to handle a variety of jumbo roll materials. This paper roll slitting machine is not only a jumbo roll cutting machine but also a paper roll slitter and rewinder, offering a comprehensive solution for paper roll processing. The Gaobao DGFQ paper roll slitting machine is renowned for its efficiency and precision, making it an essential tool in the paper industry. Whether you need a paper roll slitter rewinder or a jumbo paper roll slitting and rewinding machine, Gaobao’s DGFQ machine is the ideal choice.

PACKAGING OF GAOBAO DGFQ JUMBO PAPER ROLL SLITTING MACHINE HIGH SPEED PAPER ROLL SLITTER REWINDER MACHINE
Unwinding unit and main machine part are packed separately. We use PP plastic wrapping the machine first. Then fix the machine into wooden pallet and pack them with wooden case.

If you are looking for reliable converting equipment suppliers, please choose us, and we will be your best partner.
