Chicken Cold Room

Frozen chicken cold room
Frozen Beef cold storage
Frozen poultry cold room

The composition of Cold Storage
A complete cold room is composed of cold storage body, compressor unit, condenser, solenoid valve, filter, pressure control, oil grading accessories.
The main components of the cold storage are imported international well-known brands, which ensure that the cold storage configuration is reasonable, stable operation, good insulation performance, low consumption, high energy, excellent quality.

Application:
The temperature range of freezing cold storage is from - 15℃ to - 25℃.
It is mainly used for quick-freezing of food, medicine, and chemical raw materials.
Likes fish, meat, plasma, laboratory, Aquatic products, Meat, Fresh fruit, Vegetables.
Item No YCF10 YCF20 YCF30
Cold Room Size 5000 x 3000 x 3000mm 2400x4800x3050mm 45000 x 3200 x 3000mm
Product Load Chicken Meat Ice Cream
Initial Temp -18℃ Centigrade
Required Temp 15℃ to -20℃ -20℃ -20℃
Ambient Tem 30 ℃ 30 ℃ 30 ℃
Duration 12hours 24hours 12 hours
Equipment Semi-hermetic 5HP Semi-hermetic 3HP Semi-hermetic 5HP
Refrigeration Condenser Air-Cooled Air-Cooled Air-Cooled
Panel Thickness 100mm/150mm
Surface material S/S 304, PPGI, aluminum sheets
Door size 800*1800mm 800x1800mm(H) 800x1800mm(H)

Any size of the cold room can be customized according to customer needs.

We focus on Custom. but not selling standard size. More information please view here.
