Cast Steel Gate Valve,600LB,3 Inch,API 600,Flanged End
| Price: | US$ 100 / Set |
|---|---|
| Minimum Order: | 1PC |
| Payment Terms: | T/T |
| Port of Export: | shanghai |
Product Details
| Model No.: | Z41 | Brand Name: | STV |
|---|
| Certification: | ISO9001 |
|---|---|
| Specification: | China Cast Steel Gate Valve,China Stv Valve is Professional Manufacturer,Supplier,Exporter of Cast Steel Gate Valve,Carbon Steel Gate Valve,Stainless Steel Gate Valve from China. We Offer Best Quality |
Packaging & Delivery
| Packaging: | WOODCASE |
|---|---|
| Delivery/Lead Time: | 30DAYS |
| Production Capacity: | 1000PCS |
Product Description
Specification:
Size: 1/2"-30"
Pressure:150LB~1500LB
Body Material: Carbon Steel A216 WCB/A105 (GS-C25/ GP240GH/ 1.0619/ P285NH),, WCC, low Carbon Steel LCB, LCC, Alloy St A217 WC6, WC9, C5, C12, Stainless steel A351 CF8, CF8M, CF3, CF3M, CF8C, Duplex steel A890 GR.4A GR.5A,Etc.
Trim Material: 13%Cr,SS304,SS316, SS304L, SS316L, F11, F22 Etc
Type: Rising Stem, BB, FB, OS&Y
Operation: Hand Wheel. Gear Devices, Electricty, Etc
End: Flanged RF/ RTJ/ FM/ FF , Butt-welding(BW)
Full Port Design, , Outside and Screw(OS&Y), Bolted bonnet, Back Seal Structure
Flexible or Solid wedge, Fully guided, Choice of Solid or Split wedge
Renewable or welded seat
Extended stem design for low temperature
Optional Bypass system
Standard:
Design And Manufacture: API 600, API 6D, BS1414,Etc
Face To Face (End To End): ANSI B16.10, API 6D,Etc
Flanged Connection: ANSI B16.5, ASME B16.47 Etc
Butt Welded End: ANSI B16.25,Etc
Test And Inspection: API 598, API 6D,Etc
NO. Part Name Material
01 Body ASTM A216WCB ASTM A351 CF8 ASTM A351 CF8M
02 Seat Ring ASTM A216+13Cr ASTM A351 CF8 ASTM A351 CF8M
03 Wedge ASTM A216+13Cr ASTM A351 CF8 ASTM A351 CF8M
04 Stem ASTM A276 420 ASTM A182 F304 ASTM A182 F316
05 Gasket 304+Graphite 304+Graphite 316+Graphite
06 Bonnet ASTM A216WCB ASTM A351 CF8 ASTM A351 CF8M
07 Stud ASTM A193 B7 ASTM A193-B8 ASTM A193-B8M
08 Nut ASTM A194 2H ASTM A194-8 ASTM A194-8M
09 Backseat ASTM A216+13Cr ASTM A351 CF8 ASTM A351 CF8M
10 Packing Graphite Graphite Graphite
11 Pin C.S S.S S.S
12 Gland Bolt ASTM A193 B7 ASTM A193-B8 ASTM A193-B8M
13 Gland Nut ASTM A194 2H ASTM A194-8 ASTM A194-8M
14 Bushing ASTM A216 F6a S.S S.S
15 Gland ASTM A216WCB ASTM A351 CF8 ASTM A351 CF8M
16 Stem Nut ZcuAl10Fe3 Bronze ZcuAl10Fe3 Bronze ZcuAl10Fe3 Bronze
17 Lubricator Cu Cu Cu
18 Retaining Nut C.S C.S+Cr C.S+Cr
19 Handwheel ASTM A47 ASTM A47 ASTM A47
20 H.W. Lock Nut C.S C.S+Cr C.S+Cr
|
