CW5200 water cooling chiller for CO2 laser cutting machine
| Price: | US$ 400 |
|---|---|
| Minimum Order: | 50 |
| Payment Terms: | T/T,paypal or western union |
| Port of Export: | jinan china |
Product Details
| Model No.: | CW5200 WATER COOLING CHILLER | Brand Name: | Rubylasertech |
|---|
| Certification: | ce |
|---|---|
| Specification: |
Specification:
CW-5200AG: applied to cool a single 130W CO2 laser tube CW-5200AH: applied to a cool a single 8KW CNC spindle, welding equipment or two 100W CO2 laser tubes. CW-5200AI: applied to a cool single 50W-75W laser diode, a single15W-30W solid-state laser or a single 30W RF laser tube; Model CW-5200AG CW-5200BG CW-5200DG CW-5200AH CW-5200BH CW-5200DH CW-5200AI CW-5204BH voltage AC 1P 220V AC 1P 220V AC 1P 110V AC 1P 220V AC 1P 220V AC 1P 110V AC 1P 220V AC 1P 220V Frequency 50Hz 60Hz 60Hz 50Hz 60Hz 60Hz 50Hz 60Hz Current 2.4-3.1A 2.6-3.3A 4.5-6.5A 2.4-3.1A 2.6-3.3A 4.5-6.5A 2.4-3.1A 2.1~3.3A compressor power 0.52KW 0.5KW 0.68KW 0.52KW 0.5KW 0.68KW 0.52KW 0.5KW 0.71HP 0.68HP 0.93HP 0.71HP 0.68HP 0.93HP 0.71HP 0.68HP Refrigeration capacity 5084Btu/h 4982Btu/h 5186Btu/h 5084Btu/h 4982Btu/h 5186Btu/h 8184Btu/h 4982Btu/h 1.49KW 1.46KW 1.56KW 1.49KW 1.46KW 1.56KW 1.49KW 1.46KW 1281Kcal/h 1256Kcal/h 1307Kcal/h 1281Kcal/h 1256Kcal/h 1730Kcal/h 1281Kcal/h 1256Kcal/h Refrigerant R-22/R-410a Refrigerant charge 360g 380g 350g 360g 380g 350g 360g 380g temp.precision 0.3 centigrade Reducer Capillary protection Overcurrent protection for compressor, flow alarm, over temperature alarm Pump power 0.03KW 0.051KW 0.1KW Tank capacity 6L Inlet and outlet External D10mm brass connector Max. lift 10M 12M 25M Max. flow 10L/min 13L/min 16L/min N.W 30Kgs G.W 35Kgs Dimension 58 x 33 x 46 cm Package dimension 75 x 48 x 66 cm |
Packaging & Delivery
| Packaging: | carton |
|---|---|
| Delivery/Lead Time: | 2-3 Working days after payment received |
| Production Capacity: | 400pcs each month |
Product Description
CW5200 water cooling chiller for CO2 laser cutting machine
Summarr
CW-5200 is refrigeration type industrial water chiller of 1400W cooling capacity. It’s mainly used to have the heat generated during the laser device working that gone through the refrigerating cycle in compressor refrigeration system and eventually transferred to the air. The water temperature is able to be adjusted. There are 2 specifications as 1 water outlet/inlet and dual water outlet/inlet, applicable to cool single laser glass tube.
Features:
1400W cooling capacity; optional environmental refrigerant;
2. Compact size, long working life and simple operation;
3. 0.3 centigrade precisely temperature control;
4. The intelligent temperature controller has 2 control modes, applicable to different applied occasions; with various setting and displayfunctions;
5. Multiple alarm functions: compressor time-delay protection, compressor overcurrent protection, water flow alarm and over high / low temperature alarm;
6. Multiple power specifications;
Specification:
CW-5200AG: applied to cool a single 130W CO2 laser tube
CW-5200AH: applied to a cool a single 8KW CNC spindle, welding equipment or two 100W CO2 laser tubes.
CW-5200AI: applied to a cool single 50W-75W laser diode, a single15W-30W solid-state laser or a single 30W RF laser tube;
|
