CS DIN 3356 Globe Valve, Raised Face, DN50, PN16
| Price: | US$ 10 / Piece |
|---|---|
| Minimum Order: | 1PC |
| Payment Terms: | T/T |
| Port of Export: | FOB SHANGHAI |
Product Details
| Model No.: | J41 | Brand Name: | STV |
|---|
| Certification: | ISO9001 |
|---|---|
| Specification: | China CS DIN 3356 Globe Valve Manufacture,Stv Provides CS DIN 3356 Globe Valve, Raised Face, DN50, PN16 |
Packaging & Delivery
| Packaging: | WOODCASE |
|---|---|
| Delivery/Lead Time: | 30DAYS |
| Production Capacity: | 1000PCS |
Product Description
Product Detail
Design standard: DIN3356.
Body material: WCB.
Nominal diameter: DN50.
Pressure: PN16.
End connection: RF.
Face to face: EN558.
Working temperature:-196℃~+600℃.
Mode of operation: handwheel.
Test and inspection: EN12266.
Product Range
Body Material: Carbon Steel, Stainless Steel, Alloy Steel.
Normal diameter: 1/2"~24" (DN15~DN600).
End connection: BW, Flanged.
Pressure range: 150 LBs~2500 LBs (PN16~PN420).
Operation: Handwheel, Gearbox, Electric, Pneumatic.
Working temperature: -29℃~+560℃.
Product Keywords of CS DIN 3356 Globe Valve, Raised Face, DN50, PN16
|
