Blast Tuna Fish Cold room

Blast Cold Room for Tuna Fish
There are usually used in conjunction with cryogenic and ultra-cryogenic refrigerators.
The cold storage volume, storage temperature,the location of the unit, the opening of the storage door and the layout of the storage can be designed and customized according to the specific requirements of users to meet the needs of customers.

Super Deep-low temperature cold storage is mainly used for industrial products of low temperature detection and seafood (such as tuna, sardines and COD etc.) and pharmaceutical material storage.

Two-stage compression or cascade refrigeration system is generally used in cryogenic and ultra-cryogenic storage, which can meet the requirements of cryogenic storage temperature and ultra-cryogenic storage temperature ranging from -30℃～-45℃、-45℃～-70℃、-70℃～-105℃

The main components of the cold storage are imported international well-known brands, which ensure that the cold storage configuration is reasonable, stable operation, good insulation performance, low consumption, high energy, excellent quality.
Item No YCB01
Cold Room Size 5000 x 3000 x 3000mm
Product Load 1200 Kgs Fish
Initial Temp -18℃ Centigrade
Required Temp -40℃
Ambient Tem 30 ℃
Duration 4 hours
Equipment Semi-hermetic 20HP
Refrigeration Condenser Seawater Cooled
Panel Thickness 200mm
Surface material S/S 304 sheets
Door size 800x1800mm/1200x2000mm
Application:
The blast freezer room we supply can be used not only for tuna frozen, but also for Deep low temperature storage of other aquatic products and foods.
Deep low Temperature Storage of Biological Products
Cryogenic storage of chemicals

Any size of cold room can be customized according to customer needs.
We focus on Custom. but not selling standard size. More information please view here.
