Arc polishing machine for countertop-table top,kitchen top,vanity top,island top
Price: | US$ 33000 |
---|---|
Minimum Order: | 1 set |
Payment Terms: | 30% down payment,70% before delivery |
Port of Export: | Shekou,Yantian Or Nansha |
Product Details
Model No.: | STZY3000 | Brand Name: | Aitao |
---|
Certification: | |
---|---|
Specification: |
Processing length:600~3200mm Processing width:500~1000mm Processing thickness:10~20mm |
Packaging & Delivery
Packaging: | |
---|---|
Delivery/Lead Time: | 30 to 40 days |
Production Capacity: | 100 sets |
Product Description
1) Conveyor belt specification (mm): 9 * 500+9 * 200 2) Processing table panel length (mm): 500-3000
3) Processing table panel width (mm): 500-1000
4) Height of processing table panel (mm): 20-60 (variable thickness below 40)
5) Equipped with 2 sets of 3KW grinding surface thickness fixing assemblies, using a
dedicated motor direct connection structure, manual lifting and adjustment,
adjustable front and rear.
6) Equipped with a set of 3KW slotted assembly, using a dedicated motor direct
connection structure and pneumatic lifting.
7) Equipped with 1 set of 0.55KW polishing assembly, pneumatic lifting.
8) Equipped with 1 set of 3KW edge grinding assembly.
9) 8 sets of pneumatic arc polishing grinding heads are equipped for side polishing,
with 1 2.2KW motor for every 2 sets of grinding heads.
10) Equipped with 1 set of 1.5KW lower chamfer assembly.
11) Equipped with 10 sets of pneumatic arc polishing grinding heads, with 1 2.2KW
motor for every 2 sets of grinding heads. Among them, 2 sets of upper arc (back)
polishing and 8 sets of lower arc (front) polishing
12) The entire arc polishing action adopts a crank rocker mechanism for reciprocating
motion, with an installed power of 4KW.
13) The main transmission adopts a cycloidal needle+variable frequency speed
regulation motor, with an installed power of 3.0Kw. The conveying speed is 0.8-
1.2m/min.
14) Air consumption (L/min): 55
15) Water consumption (L/min): 450
16) Total power (Kw): 40.85
17) Working face height (mm): 835
18) The base frame is made of national standard 32 # I-beam, the main beam is made
of national standard 22 # channel steel, and the belt bottom plate is made of 3mm
thick stainless steel bottom plate
19) The electric box and control box are separated, and a suspended control box is
used, making it easy for operators to operate at different positions at the entrance
20) Overall dimensions (length x width x height) (m): 8.0x2.6x2.0
21) Weight (kg): approximately 7500
