Arc polishing machine for Step tiles,skirting,corner tiles
| Price: | US$ 21000 |
|---|---|
| Minimum Order: | 1 set |
| Payment Terms: | 30% down payment,70% before delivery |
| Port of Export: | Shekou,Yantian Or Nansha |
Product Details
| Model No.: | YHP-1200/14 | Brand Name: | Aitao |
|---|
| Certification: | |
|---|---|
| Specification: |
Processing width:100~1200mm Processing thickness:6~20mm Processing speed:1.5~7.5m/min |
Packaging & Delivery
| Packaging: | |
|---|---|
| Delivery/Lead Time: | 30 to 40 days |
| Production Capacity: | 100 sets |
Product Description
item name unit Paramaters 1 Size of conveying belt mm 300
2 Qty of edge grinding wheel pc 1
3 Dia of edge grinding wheel mm φ200-φ250
4 Qty of notching wheel pc 1
5 Dia of notching wheel mm φ150
6 Motor power for grinding KW 3
7 Chamfering wheel pcs 4
8 Motor power of chamfering KW 3
9 Wheel of bottom chamfering pc 1
10 Motor power of bottom chamfering KW 1.5
11 Dia of chamfering wheel mm φ150-φ200
12 Qty of polishing wheel pc 14
13 Dia of polising wheel mm 100
14 Motor powder of polishing KW 1.5
15 Motor powers of swinging KW 4
16 Working width mm 100-1200
17 Motor power of conveying belt KW 2.2
18 Range of conveying speed m/min 1.5-7.5
19 Tile thickness of processing mm 6-12
20 Motor power of blocking KW 0.75
21 Total powder KW 36.95
22 Air consumption L/min 55
23 Water consumption L/min 490
24 Size of external size LxWxH Appr 5.9x2.1x1.7
25 Weight kg Appr 5000
item name unit Paramaters
1 Size of conveying belt mm 300
2 Qty of edge grinding wheel pc 1
3 Dia of edge grinding wheel mm φ200-φ250
4 Qty of notching wheel pc 1
5 Dia of notching wheel mm φ150
6 Motor power for grinding KW 3
7 Chamfering wheel pcs 4
8 Motor power of chamfering KW 3
9 Wheel of bottom chamfering pc 1
10 Motor power of bottom chamfering KW 1.5
11 Dia of chamfering wheel mm φ150-φ200
12 Qty of polishing wheel pc 14
13 Dia of polising wheel mm 100
14 Motor powder of polishing KW 1.5
15 Motor powers of swinging KW 4
16 Working width mm 100-1200
17 Motor power of conveying belt KW 2.2
18 Range of conveying speed m/min 1.5-7.5
19 Tile thickness of processing mm 6-12
20 Motor power of blocking KW 0.75
21 Total powder KW 36.95
22 Air consumption L/min 55
23 Water consumption L/min 490
24 Size of external size LxWxH Appr 5.9x2.1x1.7
25 Weight kg Appr 5000
item name unit Paramaters
1 Size of conveying belt mm 300
2 Qty of edge grinding wheel pc 1
3 Dia of edge grinding wheel mm φ200-φ250
4 Qty of notching wheel pc 1
5 Dia of notching wheel mm φ150
6 Motor power for grinding KW 3
7 Chamfering wheel pcs 4
8 Motor power of chamfering KW 3
9 Wheel of bottom chamfering pc 1
10 Motor power of bottom chamfering KW 1.5
11 Dia of chamfering wheel mm φ150-φ200
12 Qty of polishing wheel pc 14
13 Dia of polising wheel mm 100
14 Motor powder of polishing KW 1.5
15 Motor powers of swinging KW 4
16 Working width mm 100-1200
17 Motor power of conveying belt KW 2.2
18 Range of conveying speed m/min 1.5-7.5
19 Tile thickness of processing mm 6-12
20 Motor power of blocking KW 0.75
21 Total powder KW 36.95
22 Air consumption L/min 55
23 Water consumption L/min 490
24 Size of external size LxWxH Appr 5.9x2.1x1.7
25 Weight kg Appr 5000
|
