AI Noise Reduction Portable Walkie Talkie Dmr Two Way Radio with GPS (BP860)

Price: US$ 520 / Piece
Minimum Order: 5
Payment Terms: T/T
Port of Export: Xiamen
Product Details
Model No.: BP860 Brand Name: BelFone
Certification:
Specification: General
Frequency Range VHF:136-174MHz,UHF:400-480MHz,UHF2:350-400MHz
Channel Capacity 1024
Zone 128
Channel Spacing 25 KHz/12.5KHz
Working Voltage DC 7.4V (¯20%)
Battery Capacity 2400mAh (3350mAh Optional)
Average Battery Life(5/5/90) 2400mAh:(without GPS) Digital 21 hours;Analog 16 hours 3350mAh:(without GPS) Digital 30hours;Analog 23hour
Frequency Stability ¯0.5ppm
Antenna Impedance 50Ω
Dimension 62(L)* 36(W)* 134(H)mm
Weight 318.5g(include battery)
Transmitter
Power Output H:4W (VHF:5W) ,L:1 W
4FSK Modulation 12.5kHz(data only):7K60FXD; 12.5kHz(data and voice):7K60FXE
FM Modulation 12.5 kHz:8K50F3E; 25 kHz:16K0F3E;
Modulation Limitation ¯[email protected]
¯5.0kHz@25kHz
FM Noise [email protected]/45dB@25kHz
Spurious Emission -36dBm<1GHz/-30dBm>1GHz
Adjacent Channel Power ≤-60dB
Frequency Response +1/-3 dB
Audio Distortion ≤5%
Digital Vocoder AMBE or NVOC
Digital Recording (Optional) ≤24 hours
Bluetooth (Optional) BT 5.0
Receiver
Digital Sensitivity 0.25μV /BER5%
Analog Sensitive 0.25uV (12dB SINAD)
Intermodulation [email protected]/25kHz
Adjacent Channel Selection [email protected]/70dB@25kHz
Spurious Suppression [email protected]/25kHz
FM Noise 40dB @ 12.5kHz;45dB @ 25kHz
Frequency Response +1/-3 dB
Rated Audio Power 1.5 W(16Ω load)
Maximum Audio Power 2.5W
Rated Audio Distortion ≤5%
Conduction Radiation -57dBm
GPS Precision Horizontal Accuracy≤10m(with good signal)
TTFF(first location)Cold Boot <1minutes(with good signal)
TTFF(first location)Hot Boot <10seconds(with good signal)
Environmental Specifications
Operational Temperature -30ºC~+70ºC
Moisture Proof By MIL-STD-810G Standard
Shock & Vibration By MIL-STD-810G Standard
Storage Temperature -40ºC-+85ºC
Dust& Water Proof IP68
Packaging & Delivery
Packaging: Standard Carton Box Packaging
Delivery/Lead Time: 15 Days
Production Capacity: 100000 Pieces/Month
Product Description
P860 is a new designed DMR radio with breakthrough advancements to cover a wider communication range, better audio effect, and quicker response. With user-friendly interactive design and excellent secure performance, BP860 brings simple, comprehensive, and efficient communication.

AI Noise Reduction: Clearer audio quality
BP860 can accurately eliminate the background and feedback noise through its AI noise reduction and acoustic model technology.

Multiple Encryptions: 100% Communication Protection
BP860 is a high secured radio that supports XOR encryption, AES256/ ARC4 encryption and optional TF card encryption for increased communication privacy.

Superheterodyne Circuit
BP860 adopts the new superheterodyne circuit design to improve its RF performance, enhance reception sensitivity, and further extend communication range. Guarantee stable reception in cross-zone switching. Ensure timely and efficient communication across a wider range.

Single Frequency Repeater Mode
BP860 can work as a SFR (Single Frequency Repeater) which perfectly solved the deficiencies of short distance coverage and crosstalk. Its SFR features significantly reduced the maintaining cost and improved the efficiency.

Three Alarms: Personnel Safety
P860 supports 3 types of alarms (lone worker/mandown/emergency alarm). In case of emergency, the alarms will be triggered manually or automatically. During the emergency period, the real positions and tracks will be sent back to the commanding center to guarantee safe and efficient rescue.

IP68 Protection
BP860 is a rugged design radio that has passed MIL-STD-810G certificate. It is made of a non-slip texture case which brings comfortable grip and excellent abrasion resistance. With IP68 certification, this BP860 is a ruggedized radio that can maintain clear audio and stable communication even after 2 meters x 2 hours beneath water.

High-precision GPS Positioning
BP860 supports a variety of precision positioning which can report real-time information, check data sms, compress data, test speed, and realize visualized command and dispatching.

Ad Hoc Networking(optional)
BP860 used multi-hop network technology to turn each Ad hoc radio into a communication signal source and form a strong communication network. It is a powerful two-way radio with characteristics of frequency-saving, easy to use, easy to carry, rapid deployment, etc. Furthermore, it also extends the communication distance and realizes signal coverage in remote areas.

Bluetooth Technology (optional)
BP860 supports optional built-in Bluetooth5.0 module. Its excellent flexibility can connect to audio device, wireless PTT, and other multiple accessories to release your hands.

Digital Recording (Optional)
With a built-in digital voice recording module, BP860 can support 100 hours voice recording with channel number and radio ID to help users query, play back, and analyze call histories
