A182 F11 Forged Globe Valve,900LB,1/2 Inch,BW End
| Price: | US$ 100 |
|---|---|
| Minimum Order: | 1PC |
| Payment Terms: | T/T |
| Port of Export: | FOB SHANGHAI |
Product Details
| Model No.: | J41 | Brand Name: | STV |
|---|
| Certification: | ISO9001 |
|---|---|
| Specification: | China A182 F11 Forged Globe Valve,China Stv Valve is Professional Manufacturer,Supplier,Exporter of A182 F11 Forged Globe Valve,Forged Steel Globe Valve,Stainless Steel Globe Valve from China. We Offe |
Packaging & Delivery
| Packaging: | WOODCASE |
|---|---|
| Delivery/Lead Time: | 30DAYS |
| Production Capacity: | 1000PCS |
Product Description
Globe Valve Applicable Standards:
Design & Manufacture according to : API 602
Face to Face according to : ASME B16.10
Flange Dimensions according to : ASME B16.5
Pressure & Temperature according to : ASME B16.34
Test & Inspection according to : API 6D / API 598
Visual Inspection according to : MSS SP-55
Marking according to : MSS SP-25
Check Valve Detail Information:
Name A182 F11 Forged Globe Valve
Model Number: J61H-900Lb-1/2"
Standard or Nonstandard: API 602
Structure: API 602 Forged Steel Globe Valve
Pressure: 900LB
Power: by medium
Material: Forged Steel ASTM A105
Temperature of Media: -29 Deg. C ~ 200 Deg. C
Media: Crude Oil, Natural Gas, etc
Port Size: 1/2" BW
Application: water, steam, oil, etc
OEM: We offer OEM service
Check Valve Optional Material:
Carbon steel ASTM A105 , etc
Low temperature steel A350 Gr. LF2 , etc
Cr-Mo steel A182 Gr. F11 , F22 , etc
Stainless Steel A182 Gr. F304 , F304L , F316 , F316L , F321 , F347 , etc
Alloy steel Alloy 20 , etc
Super duplex A182 Gr. F51 , F53 , F55 , etc
Aluminum bronze B148 C95500 , C95600 , C95800 , etc
Monel Monel K400, K500
Inconel inconel 600 , etc
Hastelloy Hastelloy B , Hastelloy C276 , etc
Incoloy Incoloy 825 , Incoloy 625 , etc
|
