6 Ton Mining Electric Trolley Locomotive
| Price: | US$ 18000 |
|---|---|
| Minimum Order: | 1 set |
| Payment Terms: | L/C,T/T |
| Port of Export: | Guangzhou |
Product Details
| Model No.: | CJY6 | Brand Name: | HUNAN YUTONG MINING EQUIPMENT |
|---|
| Certification: | CE, ISO9001:2008 |
|---|---|
| Specification: |
Total weight (t) : 6 ton
Track gauge (mm) : 500.600,762 or 900 Traction (KN) : 11.94kN Max. Traction (KN) : 14.7kN Speed(km/h) : 10km/h Voltage : 250V or 550V Power (KW) : 18kw *2 Dimensions Length(mm) : 4430mm Width(mm) : 1050,1212 or 1350mm Height(mm) : 1600 Wheelbase (mm) : 1150 mm Min Curve radius (m) : 7 m Wheel diameter (mm) : Φ680mm Controller : Resistance or IGBT Braking method : Mechanical or Hydraulic Brake |
Packaging & Delivery
| Packaging: | 1 set per wooden box |
|---|---|
| Delivery/Lead Time: | In 15 days after payment |
| Production Capacity: | 1000 sets per year |
Product Description
6 Ton Mining Electric Trolley Locomotive
Trolley electric locomotive is a kind of rail transportation traction equipment, powered by transformers and overhead lines. Mainly used in mines where there is no risk of explosion. Because of its special power supply mode, the trolley electric locomotive has no limit on the cruising range. Therefore, it is suitable for long-term and long-distance use. There are also many options in terms of speed regulation and braking methods. Speed control methods include resistance speed control, chopping speed control and frequency conversion speed control. Braking methods include pure mechanical braking, hydraulic braking and compressed air braking. In addition, electric braking can also be selected as an auxiliary braking method.
Total weight (t) : 6 ton
Track gauge (mm) : 500.600,762 or 900
Traction (KN) : 11.94kN
Max. Traction (KN) : 14.7kN
Speed(km/h) : 10km/h
Voltage : 250V or 550V
Power (KW) : 18kw *2
Dimensions
Length(mm) : 4430mm
Width(mm) : 1050,1212 or 1350mm
Height(mm) : 1600
Wheelbase (mm) : 1150 mm
Min Curve radius (m) : 7 m
Wheel diameter (mm) : Φ680mm
Controller : Resistance or IGBT
Braking method : Mechanical or Hydraulic Brake
|
