3 Ton Trolley Accumulator Locomotive with hydraulic brake
| Price: | US$ 30000 / Set |
|---|---|
| Minimum Order: | 1 set |
| Payment Terms: | L/C,T/T |
| Port of Export: | Guangzhou |
Product Details
| Model No.: | CJY3 | Brand Name: | HUNAN YUTONG MINING EQUIPMENT |
|---|
| Certification: | CE, ISO9001:2008 |
|---|---|
| Specification: |
Adhesive / total weight (t) : 3 ton
Track gauge (mm) : 600.762.900 Traction (KN) : 6.1 / 5.74 Max. Traction (KN) : 7.36 Speed(km/h) : 10.6 7.5 Power (KW) : 12KWx1 6.5KWX2 Dimensions Length(mm) : 2700, 2750 Width(mm) : 940,1102or 1240 Height(mm) : 1550, 1500 Wheelbase (mm) : 816, 850 Wheel diameter (mm) : 650, 850 Min Curve radius (m) : 5.7 6 Controller : Resistencia or IGBT Braking method : Mechanical |
Packaging & Delivery
| Packaging: | 1 set per wooden box |
|---|---|
| Delivery/Lead Time: | In 15 days after payment |
| Production Capacity: | 1000 sets per year |
Product Description
Trolley electric locomotive is a kind of rail transportation traction equipment, powered by transformers and overhead lines. Mainly used in mines where there is no risk of explosion. Because of its special power supply mode, the trolley electric locomotive has no limit on the cruising range. Therefore, it is suitable for long-term and long-distance use. There are also many options in terms of speed regulation and braking methods. Speed control methods include resistance speed control, chopping speed control and frequency conversion speed control. Braking methods include pure mechanical braking, hydraulic braking and compressed air braking. In addition, electric braking can also be selected as an auxiliary braking method.
Adhesive / total weight (t) : 3 ton
Track gauge (mm) : 600.762.900
Traction (KN) : 6.1 / 5.74
Max. Traction (KN) : 7.36
Speed(km/h) : 10.6 7.5
Power (KW) : 12KWx1 6.5KWX2
Dimensions
Length(mm) : 2700, 2750
Width(mm) : 940,1102or 1240
Height(mm) : 1550, 1500
Wheelbase (mm) : 816, 850
Wheel diameter (mm) : 650, 850
Min Curve radius (m) : 5.7 6
Controller : Resistencia or IGBT
Braking method : Mechanical
|
