22KW Horizontal Electric Mining Pulling Scraper Winch

2JP, 2JPB series rake winches (hereinafter referred to as winches) are mainly used for ore handling and filling in metal mines and other mine pits or open pits. They are used for raking on slopes with a horizontal or inclination angle of no more than 44®.
Mine harrow winches are strictly forbidden to be used to carry people. Non-flameproof harrow mine winches are strictly prohibited to be used in coal mines! After the motor is started, it is strictly forbidden to press the two joysticks at the same time!
The 2JBP-22/2JP-22 scraper winch is composed of three main parts: a winch, a rake bucket and a pulley. Mine rake winches are mainly used in the pits and open spaces of metal mines and other mines, and are used for mineral rake and filling work on horizontal and slightly inclined working surfaces.The following is the parameter table of 2JBP-22/2JP-22 scraper winch.
Model: 2JPB-22/2JP-22
Average pulling force of main wire rope (KN): 20
Main wire rope speed (m/s): 1.2
Sub wire rope speed (m/s): 1.6
Average wire rope speed (m/s): 1.4
Motor model: YBK3-180L-4/Y180L-4
Motor power （KW）: 22
Main drum rope capacity (m): 80
Main drum diameter (mm): 280
Main drum width (mm): 156
Main wire rope diameter (mm): 14
Main wire rope structure: 6×19
Main wire rope minimum breaking force (KN): 109
