18650 10s2p 36v 4400mah lithium ion battery icr18650 10s2p 36v 4.4ah battery pack 10s2p 18650 li ion

18650 10s2p 36v 4400mah lithium ion battery icr18650 10s2p 36v 4.4ah battery pack 10s2p 18650 li ion battery specification:

No.

Item

Characteristics

Remarks

3.1

Nominal Capacity

Minimum:4350mAh

Typical: 4400mAh

Standard discharge(0.2C5A)

after Standard charge

3.2

Nominal Voltage

36V



3.3

Charging Cut-off Voltage

42V



3.4

Discharge Cut-off Voltage

30V



3.5

Standard charge

Constant Current 0.5C5A

Constant Voltage 8.4V

0.01 C5A cut-off

Charge time : Approx 4.0h

3.6

Maximum Constant Charging Current

4400mA(1.0C)



3.7

Standard discharge

Constant current 0.2 C5A

end voltage 6.0V



3.8

Maximum Continuous Discharging Current

4400mA(1.0C)



3.9

Operating Temperature

Charge 0~45℃

Discharge –20~60℃



3.10

Storage Temperature

-20~45℃ for 1Month

-20~35℃ for 6Months



3.12

Environmental request

RoHS

If the materials of the product and packaging accord with RoHS standard,there will be a RoHS Id on the box.

18650 10s2p 36v 4400mah lithium ion battery icr18650 10s2p 36v 4.4ah battery pack 10s2p 18650 li ion battery feature :

Electronic Cigarette.

RC Applications, car, plane etc.

Safety, Alarm, Electric meter, power backup etc.,

Building portable power device that needs high energy density and low weight, Petroleum drill.
